TPI THA Series 3 Lamp 7.5KW Mul-T-Mount Electric Infrared Heater with 8mm Quartz Lamps and Amber Gray Sleeves - 90° Symmetrical, 208 Volts - Extruded Aluminum

Model Number: 343-90-THA-208V

Features:

• ETL C/US listed for suspended, totally exposed outdoor and indoor spot comfort heating applications, including exterior snow/ice control applications
• All 3-lamp heaters wire for either single or three-phase wiring.
• Includes surface mounting brackets
• Short wavelength radiant heat emitter for indoor & total exposed outdoor heating applications
• Gold anodized interior reflector offered in symmetrical or asymmetrical heat pattern options
• Clear quartz lamp operates at 96% radiant efficiency & generates 8-lumens per watt
• Designed for indoor and totally exposed outdoor heating application areas
• Element life expectancy of 5,000 hours
• Extruded aluminum housing
• Nickel gray finish
• Designed for commercial applications
• Chain or suspension mounting options
• Shipped with clear quartz lamps and amber gray “glare” reducing sleeves
• When used together, reduces 94% of lumens of clear quartz lamp
• Allows 90% of energy to pass through sleeve to installed area
• Eliminates red glow found with using red vycor sleeve
• Shipped standard on all AG suffix & THA model series
• Made in U.S.A.

Specifications:

• KW: 7.5
• BTUs: 25298
• Volts: 208
• Reflector Pattern: 90° Symmetrical
• 8mm Diameter Replacement Lamp: 04913202
• WT. (LBS): 33
• Mounting Height Indoor: Consult Factory
• Image shown is a representation, actual product may vary.

Note: Consult the factory, the product instruction manual, or a licensed electrician for 3-phase wiring of all 2-element heaters.
