The Leica DD120 Series Utility Locator Package (Model 6014155) is a complete solution for detecting buried utilities with advanced automatic controls, making it easy to use even for beginners. Paired with the DA220 Signal Transmitter, this package enhances accuracy and extends application range. It's designed for construction professionals, ensuring safe excavation by accurately detecting cables and pipes.
Key Features:
-
Depth Range: Detects utilities from 1 to 10 feet with 10% depth accuracy.
-
Durable Design: Built to IP54 environmental standards for dust and water resistance.
-
Transmitter Power: Up to 1-watt output for strong and clear signals.
-
Battery Life: 15 hours of operation for uninterrupted usage.
-
Complete Kit: Includes DD120 Locator, DA220 Transmitter, extension cable, carry bag, alkaline batteries, and user manual.
Specifications:
DD120 Utility Locator:
- Power Frequency: 60Hz
- Depth Range: 1ft to 10ft (Line and Sonde)
- Operating Temp: -4°F to 122°F
- Battery Life: 15 hours (Alkaline batteries)
- Weight: 5.95 lbs
DA220 Signal Transmitter:
- Frequencies: 33kHz, 8kHz, 512Hz
- Output: Up to 1 Watt
- Environmental Rating: IP67
- Battery Life: 15 hours (Rechargeable Li-ion)
- Weight: 5.25 lbs
Frequently Asked Questions (FAQ)
Q1: Can I use this system in rainy conditions?
Yes, both the DD120 and DA220 are water-resistant (IP54 and IP67, respectively).
Q2: Is the system easy to carry around?
Yes, the package includes a carry bag, and both devices are lightweight.
Q3: Can this system help me avoid hitting underground power lines?
Yes, it’s designed to locate buried cables and pipes to prevent accidents during excavation.
Q4: What type of batteries does the DD120 use?
It uses 6 AA alkaline batteries.
Q5: Is the system user-friendly?
Yes, the automatic controls make it very easy to use, even for beginners..
Q6: Is the system safe to use near live power lines?
Yes, it’s designed for safety during operations near live cables, but always follow safety guidelines.
Q7: How do I maintain the system?
Keep the devices clean, store them in the carry bag, and ensure batteries are charged or replaced as needed.
