Palmgren 22" Gear Head Drill Press 3HP 240V

Model Number: 9680225

Features:
  • The Palmgren Gear Head Drill Press is a versatile all-gear drive drill press that's perfect for precision drilling applications and continuous industrial use. With a state-of-the-art push-button electro-mechanical clutch for power feed engagement and overload protection, this drill press delivers full power at any speed. The all-gear drive transmission ensures nearly 100% of the available motor horsepower is used to drive cutting tools, while steel and reinforced fiber gears ensure positive, quiet operation. All clutches are made of ground steel for added performance and strength. With its wide speed range, this drill press is ideal for drilling small to large diameter holes quickly and easily.
  • Wide speed range with 8 different speeds
  • Simple knob selectors for operator ease in changing spindle speeds
  • Electro-magnetic clutch power feed - the operator simply dials in the desired feed rate and engages the power feed with the push of a button
  • The feed disengages automatically when the preset depth is reached
  • Fully enclosed machine tool spindle with internal MT4 mounted in precision bearings for maximum accuracy, minimizing deflection
  • Quick release drill ejector
  • Front mounted control panel designed for operator convenience
  • Forward & reverse spindle switch
  • T-slotted production table and base
  • Rack and pinion table raiser
  • Front mounted dial adjusted work stop
  • Interlocking chuck guard
  • Work light
  • Coolant system
Specifications:
  • Motor HP: 2.0 - 3.0 HP - 240V - 3PH - 60Hz
  • Swing: 22 in
  • Spindle Speeds: 90 - 2480 RPM
  • Spindle Taper: MT4
  • Spindle Travel: 4-3/4 in
  • Capacity Cast Iron: 1 - 9/16 in
  • Spindle to Table: 32-1/4 in
  • Table Work Surface: 15-3/4 x 16-1/2 in
  • Number of Speeds: 8
  • Column Diameter: 4-1/2 in
  • Power Feed: Yes
  • Base Size: 17 3/4 x 26 in
  • Drive Type: Gear Head
  • Chuck Size: 5/8 in
  • Table Slot Size: 1/2 in
  • Capacity Steel: 1 - 1/4 in
  • Quill Diameter: 2 - 61/64 in
  • Height: 86.5 in
  • Width: 23.5 in
  • Depth: 28 in
